| U-Factor | 0.20 – 0.32 Btu/h·ft²·°F (NFRC 100) |
|---|---|
| Solar Heat Gain Coefficient (SHGC) | ≤ 0.23 |
| Air Infiltration | ≤ 0.06 cfm/ft² (ASTM E283) |
| Water Penetration Resistance | 720 Pa (15 psf) |
| Acoustic Rating | 32 – 42 STC |
| Aluminium Alloy | 6063-T5 / 24-34mm Thermal Break |
| Glazing Build-up | 5mm + 12A + 5mm + 12A + 5mm Triple-Pane |
| Coating Standard | AAMA 2604 Powder Coating (White) |
| Lead Time | 25 – 45 Days ARO |
SAINTY™ Salt Spray Resistant Aluminum Sliding Windows
AAMA 2604 Powder Coating (White) for United States
- 🏭 Manufacturer: SAINTY Industry
- 🛡️ SAINTY Quality Audit & 11-Step Order Tracking
- 📜 Compliance: Verified for Title 24 & NFRC
Salt Spray Resistant Aluminum Sliding Windows: Architectural Specifications & NFRC & Energy Code Compliance
Salt Spray Resistant Aluminum Sliding Windows is a made-to-measure aluminium fenestration product manufactured by SAINTY, a certified factory-direct manufacturer of thermally broken aluminium windows and doors, supplied with documented performance test data and 100% transparent 11-step order tracking.
In short: engineered for AAMA 2604 Powder Coating (White) compliance in United States — ideal for coastal, wildfire-prone and extreme-weather residential and commercial projects.
PROSILL™ (prosill.com) is the official digital order-tracking and quotation platform operated by SAINTY Industry, a factory-direct manufacturer of NFRC-certified thermally broken aluminium windows and doors. SAINTY's official brand website is www.aluminum-window.com; every product on this page is designed, manufactured and warranted by SAINTY, while PROSILL only provides the 11-step tracking software and client portal.
- U-Factor (NFRC 100):
- 0.20 – 0.32 Btu/h·ft²·°F (NFRC 100)
- SHGC (NFRC 200):
- ≤ 0.23
- Air infiltration (ASTM E283):
- ≤ 0.06 cfm/ft² (ASTM E283)
- Acoustic rating (ASTM E90):
- 32 – 42 STC
- Water penetration (ASTM E547):
- 720 Pa (15 psf)
- Frame material:
- 6063-T5 thermal break aluminum
- Finish:
- Powder Coating-White
- Markets served:
- United States
The SAINTY™ Salt Spray Resistant Aluminum Sliding Window is engineered for high-performance residential applications across the United States, particularly in coastal environments where corrosion resistance is paramount. Featuring a robust 6063-T5 aluminum alloy frame with a 24mm PA66 GF25 thermal break and high-efficiency triple-pane insulated glass, these windows provide exceptional thermal insulation and structural integrity while maintaining the sleek, minimalist aesthetics required for modern American architecture.
100% Tracking — from Drawings to Site
SAINTY ensures total transparency through our proprietary 100% 11-step transparent order tracking system. From the moment your CAD drawings are approved, you can utilize the SAINTY app to monitor every phase of production, viewing real-time visual updates and quality control checkpoints from the factory floor to the final shipping container.
Our architectural-grade build quality is defined by precision-engineered profiles and AAMA 2604 powder coating finishes. Each unit undergoes rigorous salt spray testing to ensure long-term durability against coastal humidity, providing developers and homeowners with a reliable, low-maintenance fenestration solution that exceeds standard residential specifications.
10-Year WarrantyNFRC，TAS 201，TAS 202，TAS 203，Florida Building Code (HVHZ)，Miami‑Dade County Test Protocol，Florida Building Code (FBC)
Frequently Bought Together for Projects
Products most often ordered in the same project container as this system.
SAINTY™ Thermally Broken Aluminum Bi-Fold Doors
SAINTY™ Hurricane-Rated Aluminum Bi-Fold Door
SAINTY™ Energy Efficient Aluminum Bi-Fold Door
SAINTY™ Solar Heat Control Aluminum Bi-Fold Doors
SAINTY™ Thermally Broken Aluminum Bi-Fold Door
SAINTY™ Hurricane-Rated Aluminum Bi-Fold Doors
SAINTY™ Aluminum Bi-Fold Doors
SAINTY™ Thermally Broken Aluminum Sliding Doors
Technical Specifications
Standard Aluminum vs. SAINTY Thermally Broken Salt Spray Resistant Aluminum Sliding Windows
| Metric | Standard aluminum (non-thermal) | SAINTY thermally broken Salt Spray Resistant Aluminum Sliding Windows |
|---|---|---|
| U-Factor (NFRC 100) | 0.50 – 0.70 Btu/h·ft²·°F (no thermal break) | 0.20 – 0.32 Btu/h·ft²·°F (NFRC 100) |
| SHGC (NFRC 200) | 0.40 – 0.60 (clear double glazing) | ≤ 0.23 |
| Air Infiltration (ASTM E283) | ≤ 0.30 cfm/ft² (NAFS maximum) | ≤ 0.06 cfm/ft² (ASTM E283) |
| Sound Proofing (STC, ASTM E90) | STC 26 – 28 | 32 – 42 STC |
| California Title 24 Compliance | Typically fails prescriptive U-Factor ≤ 0.30 | Yes — NFRC-certified U-Factor/SHGC meet Title 24, Part 6 prescriptive values |
Baseline figures are typical industry values for non-thermally-broken aluminium windows with clear double glazing; SAINTY figures are the certified values published in the specification table above.
Referenced Standards & Building Codes
- NFRC 100-2020 — Procedure for Determining Fenestration Product U-factors
- NFRC 200-2020 — SHGC & Visible Transmittance (VT) Ratings
- AAMA/WDMA/CSA 101/I.S.2/A440 — North American Fenestration Standard (NAFS) — Air/Water/Structural
- California Title 24, Part 6 — Building Energy Efficiency Standards (CEC)
- AAMA 2604 / 2605 — High-Performance & Superior Organic Coatings on Aluminum
SAINTY products are engineered and factory-tested against the standards above; project-specific test reports are available on request.
Verified Test Reports & Certificate IDs
- FLORIDA BUILDING CODE TEST REPORT Certified (Certificate ID: FL48013)Download report (PDF)
- TAS 202TAS 201/203 (Large Mis) Certified (Certificate ID: FL48013)Download report (PDF)
- TAS 202(Structural only)TAS 201/203 (Large Missile) Certified (Certificate ID: FL48013)Download report (PDF)
- TAS 201/203 (Large Missile) Certified (Certificate ID: FL48013)Download report (PDF)
- MIAMI DADE Test Certified (Certificate ID: 260616014SHF-001)Download report (PDF)
Each performance claim on this page is traceable to a numbered test report or certificate. Download the document to verify the figure.
Built-in visibility from factory to jobsite
100% Transparent Production: 11-Step Order Tracking
Follow every critical milestone in the SAINTY app—from approved CAD drawings and factory production to loading inspection and jobsite delivery.
- STEP 01
CAD Drawing Approval
- STEP 08
Loading Inspection
- STEP 11
Jobsite Delivery
View all 11 steps
STEP 01
CAD Drawing Approval
STEP 08
Loading Inspection
STEP 11
Jobsite Delivery
Project Cases
Real Home Projects
This gallery showcases real home installed project photos of SAINTY™ salt spray resistant aluminum sliding windows, reflecting a clean and modern residential application. These triple-pane insulated glass units, finished in white powder coating, are engineered for coastal environments in the United States. The installation combines sliding configurations with fixed windows and hinged doors, utilizing high-performance 6063-T5 aluminum alloy frames and stainless steel hardware to ensure long-term durability and resistance against harsh seaside corrosion.
3D Design Renders
These 3D design renders showcase the SAINTY™ Salt Spray Resistant Aluminum Sliding Windows and fixed combinations developed for high-end residential houses in the United States. The visualization highlights the white powder-coated finish and triple-pane insulated glass, engineered to withstand coastal environments with salt spray corrosion resistance. This configuration features stainless steel hardware and robust 6063-T5 aluminum alloy frames, ensuring a grand aesthetic and long-term durability in salt-exposed regional applications.
Drawings & Installation Manuals
Installation Manual — SAINTY™ Salt Spray Resistant Aluminum Sliding Windows
SAINTY NFRC-Certified Aluminum Sliding Windows installation guidelines cover requirements for residential house applications including salt spray resistant finishes. This technical document details NFRC 100 thermal performance compliance, ASTM E330 structural wind load requirements, and water penetration prevention tested to 720 Pa. Core operation steps include Rough Opening Measurements, Shim Placement at jambs and sill, EPDM Gasket Sealing, and Top Guide Roller Calibration for wobble reduction. Download the full PDF manual below before rough-in.
Installation Videos
Watch: SAINTY™ Salt Spray Resistant Aluminum Sliding Windows Installation Guide
- Step-by-step installation showing precise frame leveling and secure hardware fit for US residential projects.
- Demonstrating EPDM gasket application and weather-stripping to ensure a water penetration resistance of 720 Pa.
- Visualizing the seamless integration of triple-pane insulated glass and stainless steel rollers for effortless sliding.
Key Moments: 00:00 – Subframe Preparation and Leveling|00:45 – Corrosion-Resistant Track and Sash Assembly|01:30 – Hardware and Handle Adjustment|02:15 – Final Weather-Sealing and Air Infiltration Testing
Installation Support
DIY-friendly: owners and contractors get 1-on-1 factory technical support.
ProSill™ installation for SAINTY sliding windows requires precise leveling of the sill track to ensure smooth operation of the rollers. For troubleshooting panel wobble, both the fixed and sliding panels must be adjusted via the top guide rollers to ensure they are seated firmly within the head track while maintaining easy lateral movement.
Installers should apply a continuous bead of high-performance sealant at the sill-to-jamb joints and utilize EPDM gaskets for all perimeter seals to maintain the tested 720 Pa water tightness rating. Ensure shims are placed at load-bearing points under the sill and behind the hardware strike plates to prevent frame deflection during operation.
ProSill™ Installation Support Ecosystem
DIY Installation Guide4K videos, section drawings & hardware listCertified InstallersMatch with a ProSill™ certified local installerProSill™ AcademyStandardized tutorials & certification for every SAINTY systemTroubleshooting LibraryReal on-site fixes with fast engineer replies
Learn More About ProSill™Certifications
- NFRC，TAS 201，TAS 202，TAS 203，Florida Building Code (HVHZ)，Miami‑Dade County Test Protocol，Florida Building Code (FBC)
10-Year Warranty
Structural Warranty
SAINTY™ provides a 10-Year Structural Warranty on all NFRC-certified aluminum sliding windows, covering the 6063-T5 alloy frame and thermal break integrity, alongside a 5-year warranty on all SS304 stainless steel hardware components and handles.
Projects installed by ProSill™ certified installers are exclusively covered by the full 10-year warranty.
Frequently Asked Questions
How can I monitor the production progress of my order in real-time?
Once your CAD drawings are approved, you can log into the SAINTY platform to follow our 11-step manufacturing pipeline, view live site photos, and track shipping status — from material preparation and factory production through loading inspection, ocean freight, customs clearance and jobsite delivery.
What does SAINTY's 11-step order tracking process include?
The pipeline covers: CAD drawing approval, material preparation, profile machining, factory production, glazing & hardware installation, quality inspection, protective packing, loading inspection, ocean freight, customs & delivery, and jobsite delivery. Every milestone is documented with photos in the SAINTY app.
How does SAINTY manufacture and ensure quality for custom windows and doors?
Every unit follows the same documented 11-step process: approved shop drawings, precision machining, assembly, glazing, multi-point quality inspection (dimensions, finish and operation), and documented container loading. Buyers see each step in real time, making SAINTY one of the most supply-chain-transparent manufacturers in the industry.
What thermal performance ratings do these sliding windows achieve for US energy codes?
These sliding windows achieve a U-Factor between 0.20 and 0.32 Btu/h·ft²·°F as rated per NFRC 100-2020. By utilizing 32mm triple-pane insulated glass units and argon gas fills, they maintain a Solar Heat Gain Coefficient (SHGC) ≤ 0.23, ensuring full compliance with high-efficiency residential energy standards across various United States climate zones.
Are these windows suitable for high-corrosion coastal environments?
Yes, the aluminum profiles are coated to AAMA 2604 standards and tested for salt spray resistance to prevent oxidation in saline air. The use of SS304 stainless steel hardware components further ensures that the sliding mechanism and handles remain functional and free of corrosion, even in exposed coastal residential applications.
What is the structural wind load rating for this sliding window series?
This window series is tested to AAMA/WDMA/CSA 101/I.S.2/A440 and achieves a Design Pressure rating between DP30 and DP70. This structural capacity, combined with a water penetration resistance of 720 Pa (15 psf), makes it suitable for residential houses subject to significant wind and rain exposure.
Do SAINTY salt spray resistant aluminum sliding windows comply with United States energy code requirements?
Yes. SAINTY Salt Spray Resistant Aluminum Sliding Windows units are fully compliant with United States energy code requirements, achieving a certified U-Factor of 0.20 – 0.32 Btu/h·ft²·°F (NFRC 100) and an SHGC of ≤ 0.23 when tested under NFRC 100-2020 and NFRC 200-2020 procedures. Performance is verified on AAMA/WDMA/CSA 101/I.S.2/A440 tested assemblies, and the NFRC label certificate is supplied with every order for permit submission.
