| Aluminium Alloy | 6063-T5 (Architectural Grade) |
|---|---|
| Thermal Break | 24mm - 34mm PA66 GF25 Polyamide |
| U-Factor (NFRC 100) | 0.20 - 0.32 Btu/h·ft²·°F |
| Solar Heat Gain Coefficient (SHGC) | ≤ 0.23 |
| Air Infiltration (ASTM E283) | ≤ 0.06 cfm/ft² @ 1.57 psf |
| Water Resistance | 720 Pa (15 psf) |
| Design Pressure (ASTM E330) | DP30 - DP70 |
| Acoustic Rating (STC) | 32 - 42 dB |
| Hardware Grade | 304 Stainless Steel Multi-Point Lock |
| Lead Time | 25 - 45 Days (Post-CAD Approval) |
SAINTY™ Thermally Broken Aluminum Sliding Windows
0.20 - 0.32 Btu/h·ft²·°F
- 🏭 Manufacturer: SAINTY Industry
- 🛡️ SAINTY Quality Audit & 11-Step Order Tracking
- 📜 Compliance: Verified for Title 24 & NFRC
Thermally Broken Aluminum Sliding Windows: Architectural Specifications & NFRC & Energy Code Compliance
Thermally Broken Aluminum Sliding Windows is a made-to-measure aluminium fenestration product manufactured by SAINTY, a certified factory-direct manufacturer of thermally broken aluminium windows and doors, supplied with documented performance test data and 100% transparent 11-step order tracking.
In short: engineered for 0.20 - 0.32 Btu/h·ft²·°F compliance — ideal for coastal, wildfire-prone and extreme-weather residential and commercial projects.
PROSILL™ (prosill.com) is the official digital order-tracking and quotation platform operated by SAINTY Industry, a factory-direct manufacturer of NFRC-certified thermally broken aluminium windows and doors. SAINTY's official brand website is www.aluminum-window.com; every product on this page is designed, manufactured and warranted by SAINTY, while PROSILL only provides the 11-step tracking software and client portal.
- U-Factor (NFRC 100):
- 0.20 - 0.32 Btu/h·ft²·°F
- SHGC (NFRC 200):
- ≤ 0.23
- Air infiltration (ASTM E283):
- ≤ 0.06 cfm/ft² @ 1.57 psf
- Acoustic rating (ASTM E90):
- 32 - 42 dB
- Design pressure (ASTM E330):
- DP30 - DP70
- Frame material:
- 6063-T5 thermal break aluminum
- Lead time:
- 25 - 45 Days (Post-CAD Approval)
- Warranty:
- 10-year structural warranty
SAINTY™ Thermally Broken Aluminum Sliding Windows deliver superior structural performance and energy efficiency for modern North American residential and commercial applications. Engineered with a precision 6063-T5 aluminum frame and integrated multi-point locking systems, these units provide seamless operation and enhanced security. Designed to meet rigorous thermal standards, they offer a reliable solution for projects requiring high-performance architectural glazing with a sleek, space-saving profile.
100% Tracking — from Drawings to Site
At SAINTY, we redefine manufacturing transparency through our proprietary 100% 11-step transparent order tracking system. B2B clients and developers gain real-time visual access to their production line via the SAINTY app, allowing for precise project management from raw aluminum extrusion to final crating. This eliminated uncertainty ensures your project timelines remain intact with verified progress updates.
Our architectural-grade build quality is anchored by 24mm to 34mm PA66 GF25 thermal breaks and AAMA 2604 certified powder coatings. Each sliding unit undergoes rigorous structural testing to ensure air infiltration does not exceed 0.06 cfm/ft², providing a durable, weather-tight envelope that outperforms standard builder-grade alternatives.
10-Year Warranty
Frequently Bought Together for Projects
Products most often ordered in the same project container as this system.
SAINTY™ Thermally Broken Aluminum Bi-Fold Doors
SAINTY™ Hurricane-Rated Aluminum Bi-Fold Door
SAINTY™ Energy Efficient Aluminum Bi-Fold Door
SAINTY™ Solar Heat Control Aluminum Bi-Fold Doors
SAINTY™ Thermally Broken Aluminum Bi-Fold Door
SAINTY™ Hurricane-Rated Aluminum Bi-Fold Doors
SAINTY™ Aluminum Bi-Fold Doors
SAINTY™ Thermally Broken Aluminum Sliding Doors
Technical Specifications
Standard Aluminum vs. SAINTY Thermally Broken Sliding Windows
| Metric | Standard aluminum (non-thermal) | SAINTY thermally broken Sliding Windows |
|---|---|---|
| U-Factor (NFRC 100) | 0.50 – 0.70 Btu/h·ft²·°F (no thermal break) | 0.20 - 0.32 Btu/h·ft²·°F |
| SHGC (NFRC 200) | 0.40 – 0.60 (clear double glazing) | ≤ 0.23 |
| Air Infiltration (ASTM E283) | ≤ 0.30 cfm/ft² (NAFS maximum) | ≤ 0.06 cfm/ft² @ 1.57 psf |
| Sound Proofing (STC, ASTM E90) | STC 26 – 28 | 32 - 42 dB |
| California Title 24 Compliance | Typically fails prescriptive U-Factor ≤ 0.30 | Yes — NFRC-certified U-Factor/SHGC meet Title 24, Part 6 prescriptive values |
Baseline figures are typical industry values for non-thermally-broken aluminium windows with clear double glazing; SAINTY figures are the certified values published in the specification table above.
Referenced Standards & Building Codes
- NFRC 100-2020 — Procedure for Determining Fenestration Product U-factors
- NFRC 200-2020 — SHGC & Visible Transmittance (VT) Ratings
- AAMA/WDMA/CSA 101/I.S.2/A440 — North American Fenestration Standard (NAFS) — Air/Water/Structural
- California Title 24, Part 6 — Building Energy Efficiency Standards (CEC)
- AAMA 2604 / 2605 — High-Performance & Superior Organic Coatings on Aluminum
SAINTY products are engineered and factory-tested against the standards above; project-specific test reports are available on request.
Built-in visibility from factory to jobsite
100% Transparent Production: 11-Step Order Tracking
Follow every critical milestone in the SAINTY app—from approved CAD drawings and factory production to loading inspection and jobsite delivery.
- STEP 01
CAD Drawing Approval
- STEP 08
Loading Inspection
- STEP 11
Jobsite Delivery
View all 11 steps
STEP 01
CAD Drawing Approval
STEP 08
Loading Inspection
STEP 11
Jobsite Delivery
Installation Support
DIY-friendly: owners and contractors get 1-on-1 factory technical support.
ProSill™ installation for SAINTY sliding windows requires precise leveling of the sill track to ensure fluid movement of the rollers and effective drainage through the weep holes. If panels exhibit wobble or uneven movement, check the top guide rollers and ensure the frame is square within 1/8 inch across the diagonals.
Apply high-performance sealant at all frame corners and mechanical joints. Shim placement should be concentrated at the jambs and sill to support the weight of the double-glazed units without bowing the extrusions, ensuring the multi-point lock aligns perfectly with the keepers.
ProSill™ Installation Support Ecosystem
DIY Installation Guide4K videos, section drawings & hardware listCertified InstallersMatch with a ProSill™ certified local installerProSill™ AcademyStandardized tutorials & certification for every SAINTY systemTroubleshooting LibraryReal on-site fixes with fast engineer replies
Learn More About ProSill™10-Year Warranty
Structural Warranty
SAINTY provides a 10-Year Structural Warranty on all aluminum extrusions and a 5-year warranty on SS304 hardware, contingent upon installation according to AAMA standards and regular maintenance of the sliding tracks.
Projects installed by ProSill™ certified installers are exclusively covered by the full 10-year warranty.
Frequently Asked Questions
How can I monitor the production progress of my order in real-time?
Once your CAD drawings are approved, you can log into the SAINTY platform to follow our 11-step manufacturing pipeline, view live site photos, and track shipping status — from material preparation and factory production through loading inspection, ocean freight, customs clearance and jobsite delivery.
What does SAINTY's 11-step order tracking process include?
The pipeline covers: CAD drawing approval, material preparation, profile machining, factory production, glazing & hardware installation, quality inspection, protective packing, loading inspection, ocean freight, customs & delivery, and jobsite delivery. Every milestone is documented with photos in the SAINTY app.
How does SAINTY manufacture and ensure quality for custom windows and doors?
Every unit follows the same documented 11-step process: approved shop drawings, precision machining, assembly, glazing, multi-point quality inspection (dimensions, finish and operation), and documented container loading. Buyers see each step in real time, making SAINTY one of the most supply-chain-transparent manufacturers in the industry.
What thermal performance specifications do these sliding windows meet?
SAINTY sliding windows are tested and rated per NFRC 100-2020 to achieve U-Factors between 0.20 and 0.32. By utilizing insulated glass units with argon filling and Low-E coatings, these windows maintain an SHGC of 0.23 or lower, ensuring compliance with strict energy codes while providing a Visible Transmittance (VT) between 0.40 and 0.65.
How is the structural integrity and weather resistance verified for North American climates?
All units are tested to AAMA/WDMA/CSA 101/I.S.2/A440 standards, achieving water penetration resistance at a minimum of 720 Pa (15 psf). The structural design is rated between DP30 and DP70 per ASTM E330, utilizing SS304 multi-point locks and reinforced frame joinery to withstand high wind loads and heavy precipitation.
Do SAINTY thermally broken aluminum sliding windows comply with US energy code requirements?
Yes. SAINTY Thermally Broken Aluminum Sliding Windows units are fully compliant with US energy code requirements, achieving a certified U-Factor of 0.20 - 0.32 Btu/h·ft²·°F and an SHGC of ≤ 0.23 when tested under NFRC 100-2020 and NFRC 200-2020 procedures. Performance is verified on AAMA/WDMA/CSA 101/I.S.2/A440 tested assemblies, and the NFRC label certificate is supplied with every order for permit submission.
How do SAINTY thermal break thermally broken aluminum sliding windows compare to standard non-thermal aluminium windows?
Unlike non-thermal aluminium frames, which typically show U-factors above 0.50 Btu/h·ft²·°F, SAINTY uses a 24mm - 34mm PA66 GF25 Polyamide thermal break and Low-E insulated glazing to reach a certified U-Factor of 0.20 - 0.32 Btu/h·ft²·°F. That reduces conductive heat transfer and HVAC loads substantially while meeting NFRC 100-2020 and, where applicable, California Title 24 Part 6 requirements.
